Description
Douchette code à barre laser 1D USB 32 bit handheld laser barcode scanner
Auto Sense Handheld Barcode Scanner With Stand CPU: 32 bit Scan Rate: 300 scans/sec Scanner Type: Bi-directional Indicator: Beeper and LED
Performance Characteristics | |
Light Source: | 650nm visible |
Scan Rate: | 300 scans per second |
CPU | 32 bit |
Reading Distance | 2.5 ~600mm (100% UPC/EAN) |
Width of Scan | 50mm@60mm, 220mm@200mm |
Scanner Type: |
Bi-directional |
Operation mode |
Auto Sense |
Resolution: |
3mil high resolution series / 5mil long depth field series |
Print Contrast Minimum: |
30%, minimum reflective difference |
Decode Capability: |
UPC/EAN, UPC/EAN with Supplementals, UCC/EAN 128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 128, Code 128 Full ASCII, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, RSS variants, Chinese 2 of 5, MSI/Plessey, UK/Plessey, UCC/EAN 128, Chinese code, GS1 DataBar (RSS)series |
Scanning Angle | ±65°(tilt); ±60°(pitch); ±42°(yaw) |
Physical Characteristics |
|
Interfaces Supported: |
PS2, RS232, USB for option |
Voltage: |
5V DC±5% |
Current: |
85 mA (Operating); 100 (Max) |
Indicator |
Beeper, LED |
Material |
ABS+PC |
Stand |
With |
Dimensions: |
156*68*83 mm (L*W*H) |
Weight: |
235g |
Color: |
Grey or black |
User Environment |
|
Operating Temperature: |
0℃~45℃ |
Storage Temperature: |
-40℃~60℃ |
Humidity: |
5%-90% (non-condensing) |
Electrostatic Discharge: |
Conforms to +/-15KV air discharge and +/-8KV of contact discharge |
Ambient Illumination |
0 ~ 100,000 LUX |
Drop Specifications: |
Withstands multiple 1.5m drops to concrete surface |
Laser classification |
EN60825-1, Class 1 |
